Maverick Oasis Model BG25 Methanol Plant

Maverick Synfuels > Oasis Methanol Plants > Maverick Oasis Model BG25 Methanol Plant

Maverick Oasis™ Model BG25 uses biogas as a feedstock and is designed for landfills and farms equipped with anaerobic digesters. Oasis BG25 has a capacity of 8,300 gallons per day (25 metric tons/day) and produces AA grade methanol that meets ASTM D1152 specifications.

Description

• Small-scale modular
• Skid-mounted
• Factory-built

Feedstock

• Biogas (~60% methane / ~40% CO₂, 3000 – 7000 ppm S)

Deployment

• Anaerobic Digesters, Landfill

Capacity

• 8,300 gallons per day (25 metric tons/day)

Output

• Methanol (performance guaranteed)
• AA Grade that meets ASTM D1152

Products

• Methanol
• Excess steam for use with co-located digesters or drying facilities
• Elemental Sulfur (485 pounds/day based on 4000 ppm S feed)

Footprint

• 50 feet x 100 feet with some flexibility to meet site limitations
• Overall height 60 feet for distillation columns and flue stack, majority of components less than 10 feet tall

Site Requirements

• Approximately 1 acre to accommodate storage and tanker truck access
• Storage – 70,000 gallons
• Tanker truck access
• Rail access (optional)
• Flare for emergency use only

Utility Requirements

• 4.0 GPM of demineralized water for steam and consumed in the process
• Water for cooling in a closed loop system
• 400 kWh/hr when using electric compressors

Permitting

• Permits are subject to local rules and regulations; however, emissions from Maverick Oasis BG25 do not exceed any limits for the priority pollutants.
